Introducing the Gale Designer PMSM HVLS Fan—where high-performance engineering meets modern minimalist design. Built for architects, designers, and premium commercial spaces, Gale delivers massive airflow, ultra-quiet cooling, and a sleek aesthetic that elevates any environment.
Powered by an advanced PMSM external-rotor motor and crafted with aviation-grade aluminum-magnesium blades, Gale achieves powerful airflow at under 35dB, making it the ideal statement piece for gyms, cafés, studios, restaurants, showrooms, and upscale industrial interiors.
Why Gale is the Designer’s HVLS Fan of Choice:
-
Modern minimalist design that complements premium interiors
-
Silent comfort with whisper-quiet operation below 35dB
-
High-efficiency PMSM motor for long life, low energy use, and zero maintenance
-
Aviation-grade aerofoil blades for smooth, powerful airflow
-
Wide coverage of up to 18 meters—perfect for both large and high-ceiling spaces
-
Smart stepless speed control for seamless, precise airflow adjustments
The Gale Designer HVLS Fan is more than a cooling solution—it's a design upgrade.
Effortless style. Powerful airflow. Premium comfort.
| Model | Diameter | Blade Qty | Weight | Power | Max Speed | Max Air Volume | Power Supply | Noise Level | Area Coverage |
|---|---|---|---|---|---|---|---|---|---|
| Gale 12ft. | 3600mm (12ft) | 6 | 38kg | 0.45kW | 90 RPM | 5900 m³/min | 220V / 1P | <35dB | Ø15–18m |
| Gale 10ft. | 3000mm (10ft) | 6 | 35kg | 0.45kW | 95 RPM | 4800 m³/min | 220V / 1P | <35dB | Ø12–15m |
| Gale 8ft. | 2500mm (8ft) | 6 | 30kg | 0.45kW | 100 RPM | 4260 m³/min | 220V / 1P | <35dB | Ø10–12m |
